SPA & SWIMMING POOL - RAS - 603 SR
Share |
RAS - 603 SR SIZE : 2200 MM X 2200 MM X 950 MM
SEATING
  • Seating Capacity - 3 person
  • Lounge - 2 person
WEIGHT
  • Weight-Dry/Filled - 495KGS/1845 KGS
  • Water Capacity - 357US Gallon/1350 liters
PUMPS
  • Jet Pump 1 - 2.0 HP
  • Jet Pump 2 - 2.0 HP
  • Jet Pump 3 - 2.0 HP
  • Circulation Pump - 0.53 HP
  • Air Blower - 1.0 HP
ELECTRICS
  • Control system - smart-GaoErDa Control System
  • Max Power Consumption - 8747Watt39.8A in 220V50Hz
  • Heater - 3KW/220-240VAC
  • Underwater Lighting - 5" LED
JET CONFIGURATIONS
  • Jets total (pc) - 101
  • Massage Jets (pc) - 76
  • Air Jets (pc) - 25
FILTRATION
  • Filter - Front Access filters
  • Effective Filtration Area - 100 sq. ft.
  • Ozone Generator - 50mg/h
FEATURES
  • Water Diverter (pc) - 2
  • Air Regulator (pc) - 2
  • Suctions (pc) - 2
  • Gate Valves(pc) - 4
  • Drain Valve (pc) - 1
  • Headrest pillows(pc) - 3
  • Support Frame - #304 stainless steel
  • Overflow Outlet (pc) - 1
  • Inbuilt Radio & skirt speakers - Yes
  • Wooden Skirt - Yes
